HPE ProLiant DL20 Gen10 Plus Server

 310,000.00 325,500.00 (-5%)

In stock


  • Form Factor: 1U Rack Server
  • Processor Series: Intel Xeon E-2300
  • Maximum Storage: 91.28TB
  • Number of Processors: One
  • Memory Type: DDR4
  • Maximum Memory: Up to 128GB
  • Maximum Weight: 9.46 kg
  • Dimensions: 4.32 * 43.46 * 38.22 cm
  • Suitable for Growing Businesses and Multiple Workload Environments
  • Innovative Security and Management Features
  • 24/7 Live Support
  • Quick Delivery Throughout India
  • 3 Years Warranty


Configure Now


Are you looking for a great server that can handle your day-to-day IT workloads and operations? Do you have a limited budget but do not want to comprise the server performance? Well then, the HPE DL20 Gen10 Plus Server can offer solutions for all your business needs. It is a 1U server with a portable and compact design, well suited for small and medium-sized businesses. It has a durable and strong body and can have a maximum weight of 9.46 kg. The Intel Xeon processor along with fast DDR4 RAM with ECC memory protection feature enables this server to handle the toughest of business workloads. It can provide a large storage capacity to meet the growing requirements of your business. The efficient power supplies this rack server supports distribute an optimum amount of power and ensure that no power is wasted. The innovative and sophisticated security features on this server keep it secure from viruses, malware, and cyber threats. The server management on this system is quite simple and convenient for IT admins, thanks to the HPE iLO5.

single socket 1u compact and portable rack server

Single-Socket 1U Compact and Portable Rack Server

The HPE ProLiant DL20 Gen10 Plus comes as a fantastic, compact, and portable rack server that is ideal for small, branch, and remote offices. The durable 1U form factor helps in maximizing the space efficiency as well as the powerful and flexible configuration enables it to handle various business-critical operations.

Suitable for Growing Businesses and Multiple Workload Environments

With the combination of well-thought hardware specifications and exclusive features from HP, the HPE ProLiant DL20 Gen10 Plus server is perfect for developing businesses with ever-growing needs. It can support different workload environments by offering flexible and affordable configurations on multiple operating systems like Microsoft Windows Server, Red Hat Enterprise Linux, etc.

Up to 8 Cores with Intel Xeon E-2300 Series Processor

The HPE ProLiant DL20 Gen10 Plus Server comes with an impressive processor configuration supporting one processor from the Intel Xeon E-2300 series. 4 to 8-core processors can be installed, offering speeds of up to 3.8 GHz. It has an Intel C256 Chipset and a maximum of 16 MB Intel Smart Cache.

Innovative Security, and Management Features

Many advanced security features on the HPE ProLiant DL20 Gen10 Plus server such as the UEFI Secure Boot, Silicon Root of Trust that is immutable, Secure Recovery, etc. provide a high level of security. The HPE iLO5 comes with lots of improved management tools that help in carrying out server management activities remotely.

innovative security and management features
drive options for large storage capacity

Drive Options for Large Storage Capacity

The storage configuration on the HPE ProLiant DL20 Gen10 Plus server can accommodate up to 2 hot plug LFF, 2 non-hot plug LFF or 4 + 2 hot plug SFF drives. It can have max storage of 91.28 TB and can support SAS/SATA HDDs and SSDs, and M.2 NVMe SSDs.

24-7 online chat support

24/7 Online Chat Support

Server Basket provides a 24 x7 facility of online live chat support where you can contact our tech experts for information regarding any of our servers. They can explain all the relevant details about the server to you and also clear any other queries that you might have, and offer quick resolutions for any issues.

assured 3 year warranty

Assured 3-year Warranty

This superb rack server comes with an assured 3-year warranty. Under the warranty period, if there are any issues or component failures with your HPE ProLiant DL20 Gen10 Plus server, you can get it fixed or get the faulty part replaced without paying any extra charges.


Additional information




Intel Xeon E-2300 series

Form Factor

1U Rack


128 GB

Memory type

HPE DDR4 Standard Memory

Drive Type

LFF (3.5), SFF (2.5)

Type of Storage


Drive supported

2 Non-hot plug LFF or 2 Hot plug LFF or 4+2 Hot plug SFF

Max Storage

91.28 TB

No of Lan Ports


No of Processors


PCI Slots


Power Supply


Refurb or New


Remote Management



3 Years

Reviews (0)

Be the first to review “HPE ProLiant DL20 Gen10 Plus Server”

Your email address will not be published. Required fields are marked *


There are no reviews yet.


What type of processors does the HPE ProLiant DL20 Gen10 Plus support?

HPE DL20 Gen10 Plus Server supports a range of Intel Xeon E-2300 series, turbo Boost Technology frequencies as high as 5.1 GHz With this processor, we can achieve fast processing output without any lag. The compatible processors include 8 core models - E-2388G 3.2GHz 95W, E-2378G 2.8GHz 80W, and E-2378 2.6GHz 65W with part numbers P45266-B21, P45262-B21, & P45260-B21, 6-core models E-2386G 95W 3.5GHz, E-2356G 3.2GHz 810W, and E-2336 2.9GHz 65W with part numbers P45264-B21, P45256-B21, &  P45254-B21, and 4-core models E-2374G 3.7GHz 80W, E-2334 3.4GHz 65W, E-2324G 3.1GHz 65W, and E-2314 2.8GHz 65W with part numbers P45258-B21, P45252-B21, P45250-B21, & P45248-B21.

What is the maximum amount of RAM supported by the HPE ProLiant DL20 Gen10 Plus Server?

The maximum supports RAM up to 128 GB of supports DDR4 Registered (RDIMM) or Unbuffered (UDIMM) ECC (Error-Correcting Code) memory, it helps to do more demanding tasks easily  like, video editing, or running virtual machines 1Rx8 8GB, 1Rx8 16GB, and 2Rx8 32GB modules with part numbers P43016-B21, P43019-B21, and P43022-B21.

What Are The Server’s Maximum Weight And Dimensions?

The server has a light footprint, with a maximum weight of around 9.46 kgs. Its dimensions are 4.32 * 43.46 * 38.22 cm. At this compact size, this server can fit into most racks.

Does the DL20 Gen10 Plus system support a dual power supply, and how much power does it consume?

No, the server supports a redundant non-hot-plug 290W power supply having power efficiency of Platinum, either from ATX or HPE.and it consumes around 290 W of power while it operates, This is at 92% system efficiency & power supply remains stable, ensuring continuous server operation. The redundant power supply modules compatible for the DL20 Gen10 plus platform are platinum 500W Flex Slot Low Halogen PSU with part number 865408-B21, 48VDC 800W Platinum LH PSU with part number 865434-B21, and 800W Titanium LH PSU with part number 865438-B21.

What Benefits Does ServerBasket Offer When I Purchase HPE DL20 Gen10 Plus Server?

If you purchase the HPE DL20 Gen10 plus server from Server Basket, you get several advantages. The most important among these is 24X7 live support where your queries get answered no matter what. We also offer speedy delivery and a 3-years warranty with the server.

What Are The Primary Specifications Of The HPE DL20 Gen10 Plus Server?

This server has a 1U rack form factor and runs the Intel Xeon E-2300 processor. With maximum storage of 91.28 TB and super fast DDR4 memory, this server is suitable for growing firms and can easily adapt to multiple workload environments.
