HPE ProLiant DL20 Gen10 Plus Server

 310,000.00 325,500.00 (-5%)

In stock


  • Form Factor: 1U Rack Server
  • Processor Series: Intel Xeon E-2300
  • Maximum Storage: 91.28TB
  • Number of Processors: One
  • Memory Type: DDR4
  • Maximum Memory: Up to 128GB
  • Maximum Weight: 9.46 kg
  • Dimensions: 4.32 * 43.46 * 38.22 cm
  • Suitable for Growing Businesses and Multiple Workload Environments
  • Innovative Security and Management Features
  • 24/7 Live Support
  • Quick Delivery Throughout India
  • 3 Years Warranty


Configure Now


Are you looking for a great server that can handle your day-to-day IT workloads and operations? Do you have a limited budget but do not want to comprise the server performance? Well then, the HPE DL20 Gen10 Plus Server can offer solutions for all your business needs. It is a 1U server with a portable and compact design, well suited for small and medium-sized businesses. It has a durable and strong body and can have a maximum weight of 9.46 kg. The Intel Xeon processor along with fast DDR4 RAM with ECC memory protection feature enables this server to handle the toughest of business workloads. It can provide a large storage capacity to meet the growing requirements of your business. The efficient power supplies this rack server supports distribute an optimum amount of power and ensure that no power is wasted. The innovative and sophisticated security features on this server keep it secure from viruses, malware, and cyber threats. The server management on this system is quite simple and convenient for IT admins, thanks to the HPE iLO5.

single socket 1u compact and portable rack server

Single-Socket 1U Compact and Portable Rack Server

The HPE ProLiant DL20 Gen10 Plus comes as a fantastic, compact, and portable rack server that is ideal for small, branch, and remote offices. The durable 1U form factor helps in maximizing the space efficiency as well as the powerful and flexible configuration enables it to handle various business-critical operations.

Suitable for Growing Businesses and Multiple Workload Environments

With the combination of well-thought hardware specifications and exclusive features from HP, the HPE ProLiant DL20 Gen10 Plus server is perfect for developing businesses with ever-growing needs. It can support different workload environments by offering flexible and affordable configurations on multiple operating systems like Microsoft Windows Server, Red Hat Enterprise Linux, etc.

Up to 8 Cores with Intel Xeon E-2300 Series Processor

The HPE ProLiant DL20 Gen10 Plus Server comes with an impressive processor configuration supporting one processor from the Intel Xeon E-2300 series. 4 to 8-core processors can be installed, offering speeds of up to 3.8 GHz. It has an Intel C256 Chipset and a maximum of 16 MB Intel Smart Cache.

Innovative Security, and Management Features

Many advanced security features on the HPE ProLiant DL20 Gen10 Plus server such as the UEFI Secure Boot, Silicon Root of Trust that is immutable, Secure Recovery, etc. provide a high level of security. The HPE iLO5 comes with lots of improved management tools that help in carrying out server management activities remotely.

innovative security and management features
drive options for large storage capacity

Drive Options for Large Storage Capacity

The storage configuration on the HPE ProLiant DL20 Gen10 Plus server can accommodate up to 2 hot plug LFF, 2 non-hot plug LFF or 4 + 2 hot plug SFF drives. It can have max storage of 91.28 TB and can support SAS/SATA HDDs and SSDs, and M.2 NVMe SSDs.

24-7 online chat support

24/7 Online Chat Support

Server Basket provides a 24 x7 facility of online live chat support where you can contact our tech experts for information regarding any of our servers. They can explain all the relevant details about the server to you and also clear any other queries that you might have, and offer quick resolutions for any issues.

assured 3 year warranty

Assured 3-year Warranty

This superb rack server comes with an assured 3-year warranty. Under the warranty period, if there are any issues or component failures with your HPE ProLiant DL20 Gen10 Plus server, you can get it fixed or get the faulty part replaced without paying any extra charges.


Additional information



Drive Type

LFF (3.5), SFF (2.5)

Form Factor

1U Rack


128 GB

Max Storage

91.28 TB

No of Lan Ports


No of Processors


PCI Slots


Power Supply



Intel Xeon E-2300 series

Refurb or New


Remote Management


Type of Storage



3 Years

Reviews (1)

Average Rating


( 1 Review )
5 Star
4 Star
3 Star
2 Star
1 Star
Add a review

Your email address will not be published. Required fields are marked *

1 Review For This Product

  1. 01

    by Vihaan

    I don’t know why I always go for HP products. Second, “Server Basket” is another term for trust. I always buy all my server systems from this platform, and they all just run amazingly.


What are the primary specifications of the HPE DL20 Gen10 Plus server?

This server has a 1U rack form factor and runs the Intel Xeon E-2300 processor. With maximum storage of 91.28 TB and super fast DDR4 memory, this server is suitable for growing firms and can easily adapt to multiple workload environments.

What are the server’s maximum weight and dimensions?

The server has a light footprint, with a maximum weight of around 9.46 kgs. Its dimensions are 4.32 * 43.46 * 38.22 cm. At this compact size, this server can fit into most racks.

Does the DL20 Gen10 Plus system support a dual power supply?

No, the server supports a redundant non-hot-plug 290W power supply having power efficiency of Platinum, either from ATX or HPE. The power supply distributes an optimum amount of power to make sure no power is wasted.

How much power does it consume?

The HPE DL20 Gen 10 plus server consumes around 290 W of power while it operates. This is at 92% system efficiency. The power supply is stable and ensures the server stays powered throughout its operation period.

What benefits does ServerBasket offer when I purchase HPE DL20 gen10 Plus server?

If you purchase the HPE DL20 Gen10 plus server from Server Basket, you get several advantages. The most important among these is 24X7 live support where your queries get answered no matter what. We also offer speedy delivery and a 3-years warranty with the server.
